Press
The eight station Brass Smith All-American 8 Press is the most feature-packed, rugged turret press on the market! Starting at the top, the extra-large 8 station turret is machined out of heavy duty cast iron. It is equipped with an easily removed turret bolt which makes swapping turrets simple. The 8 die station turret is the largest available and will hold two complete 4 die sets or up to four 2 die sets. Below the turret is a rigid cast iron frame, housing a 1” diameter ram and compound linkage. The frame is large enough to work with even the longest rifle cartridges. Work the press handle and you will feel the tight, precision fit and smooth operation.
Unlike many competitive presses, the Brass Smith All-American 8 Press comes with a newly designed straight line primer feed. The straight line primer feed is completely reliable and simple to use. Simply push the priming arm forward at the bottom of the ram travel to position it beneath the shell holder. For added safety, the primer feed comes with a heavy steel shield which surrounds the primer tubes. The Brass Smith All-American 8 Press is equipped with a comfortable ball handle which can be positioned for either right or left hand use.
The Brass Smith All-American 8 Press is designed for use with any standard 7/8”x14 thread dies and accepts standard shell holders.
• Heavy duty cast iron frame and turret
• Extra-large 8 station turret is easily removed to make swapping turrets simple.
• Holds two complete 4 die sets or up to four 2 die sets
• 1” diameter ram
• Comes with straight line primer feed with large and small primer tubes
• Precision fit and smooth operation
• Large press opening, works with the largest cases
• For added safety, the primer feed comes with a heavy steel shield which surrounds the primer tubes.
• Right or left hand operation
• Durable powder coat finish
• Weight 23 pounds
Shellholder
The Lyman Shellholder set fits more than 75 different calibers!
Includes 12 of the most used shellholders which fit the most popular pistol and rifle calibers. Comes in a handy compartmented storage box. Includes shellholders #1,2,6,7,11,12,13,14B,15,17,22 & 26. Save 60% over buying individually.
Shellholder number |
Pistol Caliber |
Rifle Caliber |
1 |
.38/.357Mag, .357 Remington Maximum |
5.6x50R Mag |
2 |
.45 ACP/.45 Win Mag |
22/250,.308 Winchester,.30-06,.243 Winchester,244, 6mm Remington,.25-06 Remington,.250-3000 Savage,6.5 Creedmoor,.260 Remington,6.5x57 Mauser,.270 Winchester,7mm/08 Remington,7x57 Mauser,7x64 Brenneke,.280 Rem (7mm Express),.300 Savage,7.65 Argentine Mauser,8x57 Mauser,8x57 JS,7.9x57,.35 Remington,.358 Winchester,.35 Whelen,9.3mm x 62 |
6 |
|
7-30 Waters,.30-30,.307 Winchester,.32 Winchester Special,.356 Winchester,.375 Winchester,.38-55 |
7 |
.44 Mag/Spl/.44 Russian,.460 S&W, .50 Action Express |
.303 British |
11 |
.45 Colt,.454 Casull |
|
12 |
9mm Luger, 9 x 23mm, .30 Luger,.30 Mauser,.38 Super Auto, 41 Action Express |
|
13 |
|
7mm Remington Mag,7mm Weatherby Mag,7mm STW,7mm Rem. Ultra Mag,.300 Winchester Mag,.300 Remington Ultra Mag,.300 Remington Ultra Mag SA,.300 Weatherby Mag,8mm Remington Mag,.375 Ruger,.375 H&H Magnum,.375 Rem. Ultra Mag,.450 Marlin |
14B |
.44-40 Winchester,.45 Schofield |
6.5x57R Mauser,7x65R Brenneke,8x57 JRS,.44-40 Winchester,.444 Marlin |
15 |
.40 S&W & 10mm |
|
17 |
.480 Ruger,.500 S & W |
7.62x54 Russian,.40-60 Win,.40-65,.416 Rigby,.45-60, .45-70 & 45-90,.45-100,.45-110,45-120 |
22 |
|
.50-70 Government,.50-90,56-50 Spencer |
26 |
7mm TCU,.380 Auto |
.17 Remington,.204 RuA5:C13ger,.221 Fireball,.222 Remington,.222 Remington Mag,.223 Remington,.300 AAC |
|
